01-120W LED Explosion Proof Light Part No.01-120W for Indoor/Outdoor Applications
Product Details:
| Place of Origin: | Jiangsu, China |
| Brand Name: | ileding |
| Certification: | ETL DLC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 pieces |
|---|---|
| Price: | $95.00/pieces 2-99 pieces |
|
Detail Information |
|||
| Color Temperature(CCT): | 3000 - 6500K, 2700-6500k | Input Voltage(V): | 100-277VAC 50/60Hz |
|---|---|---|---|
| Lamp Luminous Efficiency(lm/w): | 140 | Warranty(Year): | 5-Year |
| Color Rendering Index(Ra): | >70 | Support Dimmer: | Yes |
| Lighting Solutions Service: | Lighting And Circuitry Design | Lifespan (hours): | 50000 |
| Working Time (hours): | 50000 | Product Weight（kg）: | 2 |
| CRI (Ra>): | 70 | Lamp Luminous Flux(lm): | 140 |
| IP Rating: | IP66 | Working Lifetime(Hour): | 50000 |
| Working Temperature(℃): | -40 - 65 | Light Source: | LED |
| Product Name: | Hazardous Location LED Linear Light | Part No: | 01-120W |
| Dimension: | 1299*130*205 Mm 51.14''*5.11''*8.2'' | Color Temperature: | 3000 - 6500K |
| Waterproof Rating: | WET (IP66) | Power: | 30/50/80/100/120/150/200W |
| Application: | Chemical Industry | ||
Product Description
| Product name | Hazardous Location LED Linear Light |
| Part No | 01-120W |
| Dimension | 1299*130*205 mm 51.14’’*5.11’’*8.2’’ |
| Color temperature | 3000 - 6500K | ||
| CRI | >70 | ||
| Cover | Diffuser+ clear glass | ||
| Lumen | 14400-17400LM | ||
| Lumen Efficacy | 140 LM/W (130-145 LM/W) | 130 LM/W (120-135 LM/W) | 140 LM/W (130-145 LM/W) |
| Viewing Angle | 20°,30°,35° | 60°,80° | 110*100° |
| Input Power | 120W | ||
| Input Voltage | 100-277VAC 50/60Hz | ||
| Driver Brand | China Brand Driver 10KV(SOSEN-SS-150VA-56BHL) | ||
| PF | >0.9 | ||
| Waterproof Rating | WET (IP66) | ||
| Explosion-proof Mark | North America: Class I ,Division 2,Groups A,B,C,D,T5; | ||
| LED Brand | Seoul |
| LED Type | SMD 3030(1.0W) |
| LED QTY | 288 PCS(120W) |
| Housing | Aluminum |
| Housing color | Yellow / Gray |
| Operating Temperature | -40℃ TO 65℃ |
| Operating Humidity | 10%-90% RH |
| Storage Temperature | -40℃ TO 80℃ |
| Storage Humidity | 10%-95% |
| Application | Indoor/Outdoor |
| Safety Certification | UL/cUL |
| Warranty Time | 5 Years |
| Size | Qty / Carton | Net weight | Gross Weight / Carton | |
| Lamp Outer box | 1410*220*305mm | 1 PC | 16.62kg | 19.5kg |
| Troubles | Check points |
| Flickering of the light | Turn off the power and turn on again in 3 minutes. If same phenomena occur, then call agencies. |
| Out of working | Please check the connection. |
Q1: Are you are a factory or a trading company?
We are the factory and we have our own die-casting workshop.
Q2: All products have a warranty?
Yes, all products have 5 years warranty at least.
Q3: Can you put our brand name or logo on our products?
Yes, we support ODM and OEM service.
Q4: Can i have a sample order for LED light?
Yes, we welcome sample order to test and check quality. Mix samples are acceptable.
Q5: How to deal with the faulty?
Firstly,we have strict quality control over our products and the defective rate will be less than 0.2%.
Secondly, if there are some problems, please contact with us. We can discuss how to deal with them
until you are satisfied.
